Upper Roller Universal Plate Bending MachineEconomical and practical fully hydraulic 3-roll bending machine with pre-bending. Rolls length up to 6.000mm, plate thickness up to 150 mm, we can design and manufacture special rolling machine according to customer request. Widely used in petroleum, chemical, boiler, shipbuilding, hydropower, metal structure and machinery manufacturing industries.

Features:

1. This machine is particularly suitable for medium plate and stainless plate for the production of cylinders and varying radiuses parts. 2. Top roll is driven by oil cylinder, move up and down, and horizontal.  3. Two bottom Rolls are powered by motor, reducer, gear.   4. Hydraulic drop-end for ease of finished cylinder removal  5. Easy operation with working table 6. Pre-bending function 7. Digital read-outs 8. Steel welded heavy frame construction, strong and solidity 9. High tensile hardened rolls, heat treated 10. Hydraulic balancing device

Composed Of Equipment:

(1) Top roller structure including two main cylinders, bearing block, heavy duty self-aligning spherical roller bearings, top roller 42CrMo, heat treated.

(2) Bottom roller structure, including bearing block, bottom roller, gear etc and horizontal movement for pre-bending, including motor, speed reducer, worm gears etc

(3) Support roller structure for supporting the bottom rollers, including rollers, bearing block, connection etc.

(4) Main drive structure including main motor, brake, main speed reducer etc

(5) Tip device for removal the finished product, including slide and cylinder

(6) Hydraulic system  Including gear pump, hydraulic valve, connection and other hydraulic parts etc  Japan Yuken hydraulic valve, easy and convenient for maintenance and adjustment  Famous Changyuan gear pump, high performance, low noise.  (7) Electrical system  Including electrical cabinet, moveable operation table, remote controller.  Working voltage is 380V 50Hz  PLC programmer is Delta from Taiwan, less relay, reliable motion, long life  Main parts are from Siemens or Schneider, high quality and reliable.

Components Of Equipment:

Hydraulic elements: YUKEN/Japan  Emergency system: Emergency push button on control panel  Electric equipment: Siemens / Schneider  PLC: Delta / Taiwan  Motor: Shandong Kaiyuan Group  User's manual in English

Rolling Process:

Cone Bending Device & Side Supports Optioal

How To Lubricate Metal Plate Bending Machine?

When the rolling machine is in use, if there is a problem of wear and gear, we should think about whether it is lack of maintenance. At this time, we need to add some lubricating oil to it, so that it can better achieve the lifting effect in operation. This is also an effective method, so how do we need to add it in the process of use? 1. Each lubrication point is sufficiently lubricated before the rolling machine is started; 2. The gearbox should be replaced with new oil after 300 hours of use, and once every 3 to 6 months; 3. When the machine is working continuously, the manual lubrication point is once every 8 hours; 4. The lubricating oil is clean, meets the standard, and must not allow impurities to be mixed; 5. All sliding mating surfaces should be kept clean, and the oxide scale dust generated in the production process should be removed in time to prevent early wear of parts; 6. Manually lubricate the machine with 3# calcium-based grease or lithium-based grease.

This model device adopts the Japanese technology. It can roll plate to cylinder, cone, U-shape and so on. The up roller of this device can do up and down, right and left move. And all the move actions can show by figure.It with the pre-bending capacity.
